Mechanics before the model
Three ways to study
structural behavior.
Choose an analysis from the physical problem: the importance of inertia, the loading path and the response you need to understand.
Choose an approach
The question determines the method
| Approach | Physical emphasis | Typical response measures |
|---|---|---|
| Static | Equilibrium under prescribed loads; inertia neglected. | Displacement, reactions, force distribution, capacity and stability. |
| Quasi-static | A slowly evolving load path; inertia remains negligible. Loading may be monotonic or cyclic. | Load–displacement curves, hysteresis, degradation and residual deformation. |
| Dynamic | Time-dependent motion with inertia and damping represented. | Periods, modes, displacement and acceleration histories, peak and residual response. |
Quasi-static describes a physical approximation. Depending on the problem, it can be implemented with a static procedure or a suitably checked dynamic procedure. See the Abaqus quasi-static analysis guide.
Equilibrium & capacity
Static analysis
Static analysis balances applied loads and internal resisting forces while neglecting inertia. It can describe a linear elastic response or trace nonlinear behavior associated with cracking, plasticity, contact and geometric change.
Questions it can address
- How are loads transferred through members and connections?
- Where do deformation and damage concentrate?
- How do material and geometric nonlinearities influence capacity?
What to examine
- Reactions and overall force equilibrium.
- Load–displacement response and changes in stiffness.
- Stress, strain, interface slip and the governing mechanism.
Load control and displacement control
Under load control, the applied load factor is incremented. Under displacement control, the increment at a selected degree of freedom is prescribed and the load factor is solved for. The control variable and loading strategy should be chosen to follow the response path of interest; severe instability may require another path-following method.
Procedure reference: OpenSees — DisplacementControl.
Interpret the mechanism. A peak on a capacity curve should be considered alongside the deformation pattern, material state and numerical behavior. A failed increment alone does not identify physical failure.
Loading history & damage
Quasi-static analysis
In a quasi-static process, loading evolves slowly enough that inertia does not materially affect the response. Monotonic loading explores a single progression of demand; reversed cyclic loading also reveals the effects of unloading, reloading and accumulated damage.
Define the loading protocol
- State whether loading is force-controlled or displacement-controlled.
- Specify amplitudes, sequence, repetitions and termination criteria.
- Represent sustained axial load and the relevant boundary conditions.
Read the cyclic response
- Compare envelopes and individual hysteresis loops.
- Define how stiffness, strength and residual deformation are measured.
- Interpret pinching and energy dissipation with the observed mechanism.
Check the quasi-static assumption
When an explicit dynamic solver is used to approximate a quasi-static process, review kinetic energy relative to internal energy and inspect whether loading rate or mass scaling changes the response. A small energy ratio supports the check, but its history and the quantities of interest also matter.
Procedure reference: Abaqus — Quasi-Static Analysis with Abaqus/Explicit.
Match more than the envelope. Similar peak loads can coexist with different unloading stiffness, loop shapes and residual deformations. Use the response measures that matter to the research question.
Inertia, damping & time
Dynamic analysis
Dynamic analysis follows structural motion under time-varying excitation. Mass and damping participate in equilibrium, so the response depends on both the structure and the characteristics of the input.
Establish the model
- Review mass sources, constraints and initial conditions.
- Inspect natural periods and mode shapes.
- Choose a damping representation consistent with the intended response.
Document the excitation
- State the record source, units, direction and scaling.
- Describe processing and the duration of the analysis.
- Check the integration time step against the response quantities.
Modal and time-history perspectives
Modal analysis characterizes the vibration properties of a model. Time-history analysis calculates response as the excitation evolves, using modal or direct-integration procedures where appropriate. The selected procedure determines which nonlinear behavior can be represented.
Procedure reference: CSI — Time-history analysis. OpenSees also distinguishes static and transient analysis objects.
Check sensitivity in time. Review how a smaller integration step affects peak demand, residual deformation and important response histories. Solver completion alone does not establish time-step independence.
Make the result inspectable
What a useful analysis report contains
- Purpose and scope. The physical question, response measures and relevant assumptions.
- Model and inputs. Geometry, units, materials, interfaces, supports, loading and initial conditions.
- Numerical checks. Equilibrium, convergence behavior, mesh or time-step sensitivity and energy checks where applicable.
- Evidence and interpretation. Benchmark or experimental comparisons, governing mechanisms and the effect of uncertain parameters.
